Why we have to choose using RFID in the
Warehouse?
As we all know, RFID is becoming more and more popular in many industries for a variety of applications.
Such as in warehouse：
1. The products will be read in in a specified range, even we don't we don't
have to check where's the RFID tags , it means that we save to much time to
tracking the products and then effectively to improve our work .
2. NFC tags can store reach up to 100
times the data of barcodes , allowing you to keep track of all the data you
need for your inventory For example, lot and serial number, size, manufacturer,
vendor, expiration date, user, location on production line and anything else
you might want to know.
3. It can be read up to 200 tags at once.
Not only to increasing speed and productivity,
but also employees will not need to physically scan each label.
4. RFID warehouse tags have a great
performance waterproof and with environments and high temperatures.
Products Details :
Material: Coated paper,PVC,PET or customized
Operating Mode :Passive
Antenna Size: 70*17mm
Inlay size: 80*25.797mm
Chip: FM1108、S 50 or customized
Memory: 144byte
Protocol: ISO14443A
Frequency: 13.56MHz
Reading Range: HF:0-5cm(depends on the reader and antenna)
Reading/Writing Endurance: ≥100000 cycles
Inlay Format: In roll
Other Chip Available : Ntag213/215/216,Alien H3, Monza 4D/4E/4QT, etc.
Other Applications:
-Supply Chain
-Inventory
-Logistics
-Apparel
-Retail
-Returnable Transport Units, etc.
Packaging ：
Selling Units: Single item
Carton size:
|
Quantity |
Carton Size |
Weight(KG) |
Volume(cbm) |
|
200 |
20*20*20cm |
0.5 |
0.008 |
|
1000 |
25*25*20cm |
1 |
0.013 |
|
2000 |
50*25*20cm |
1.5 |
0.025 |
|
4000 |
50*50*20cm |
3 |
0.05 |
